The BluSDR-30 is a 2W software defined radio module that carries a self-healing tactical mesh across medium-range UxV links up to 30km on small drone platforms.
Two COFDM transceivers deliver 1W (+30dBm) per output for 2W total, with 0.25dB incremental control.
Tuned for medium-range UxV links up to 30km on small drone platforms and mobile nodes.
MeshUltra-X MANET waveform forms a self-healing mesh of up to 144 nodes with capacity up to 87Mbps.
Clamshell and Plain variants accept USB-C power compliant with USB PD, direct from device or battery.
Gigabit Ethernet, RS-232 serial, dual USB, and on-board headset audio cover most payload interfaces.
Robust Boxed variant rated IP68, with EMC screening included across the module range.
Optional AES128/256 accredited to FIPS140-2 for MeshUltra. Internal microSD 128GB onboard storage.
| Radio Architecture | SOL8SDR software defined radio |
|---|---|
| Mesh Waveform | DTC MeshUltra-X MANET IP Mesh, up to 144 nodes |
| Mesh Capacity | Up to 87Mbps MeshUltra |
| Protocols | SBUS and MAVLink supported |
| Data Interface | RS-232 or USB peripherals; Gigabit Ethernet |
| Data Configuration | 1k2 to 115k2, 7/8 bit, no/odd/even parity |
| Audio Interface | Analogue mic/head with bias; G726 32kbit, 8kHz sampling, with mute |
| USB Peripherals | 3G/4G/Wi-Fi dongles supported; RNDIS Ethernet over USB |
| USB-C Power | USB PD compliant (Clamshell and Plain variants) |
| Encryption (standard) | DES |
| Encryption (licensed) | AES128/256, accredited to FIPS140-2 for MeshUltra waveforms (subject to export control) |
| Storage | Internal microSD 128GB |
| Build Options | Clamshell Core, Plain Boxed, Robust Boxed |
| RF COFDM Transceivers | 2x; MMCX 50 ohm (Clamshell), SMA 50 ohm (Plain), TNC 50 ohm (Robust) |
|---|---|
| RF Power | 1W (+30dBm) per output, 2W total |
| Power Step | 0.25dB incremental control |
| Tuning Step | 125kHz |
| Bandwidth | 1.25/1.5/1.75/2.5/3.0/3.5/4.0/5.0MHz (MeshUltra-M/-80/-X)6.0/7.0/8.0/10.0/12.0/14.0/16.0/20.0MHz (MeshUltra-M/-80) |
| Carrier Modulation | BPSK/QPSK/16QAM/64QAM (adaptive) |
| FEC Rate | FEC1/2, FEC2/3 (adaptive) |
| Receive Sensitivity | -98dBm (BW 2.5MHz/QPSK 1/2) |
| Receive Input Level | +20dBm max. |
| Frequency Options | 1.20 to 1.70GHz1.78 to 2.29GHz1.98 to 2.70GHz4.40 to 5.00GHz5.50 to 6.00GHz |
| Dimensions (Clamshell Core) | 95mm x 60mm x 15mm |
|---|---|
| Weight (Clamshell Core) | 110g |
| Dimensions (Plain Boxed) | 150mm (160mm incl. connectors) x 75mm x 24mm |
| Weight (Plain Boxed) | 462g approx. |
| Dimensions (Robust Boxed) | 157mm (165mm incl. mounting) x 75mm x 21mm |
| Weight (Robust Boxed) | 430g approx. |
| DC Input | 8 to 17V, overvoltage protected up to 30V |
| Power Consumption | 12W RMS @13V (25% data occupancy); 18W RMS @13V (100% data occupancy) |
| Inrush Current (power up) | 10A @13V |
| Temperature Range | -20 to +55 °C, with additional cooling for the Clamshell variant |
| Humidity | Less than 85% non-condensing |
| Sealing (Robust Boxed) | IP68 |
BluSDR-30 delivers a full 2W of software defined radio power for medium-range UxV missions up to 30km without forcing an interface or sealing compromise. Operators gain a self-healing tactical mesh of up to 144 nodes, AES128 and AES256 encryption accredited to FIPS140-2, and Gigabit Ethernet with USB-C PD powering. An IP68 Robust Boxed option handles sealed, wet field conditions. Across small drones, mobile teams, and fixed nodes, the BluSDR-30 keeps the link alive in contested spectrum.
