BluSDR-90-UL

SOFTWARE DEFINED RADIO MODULE

Low-SWaP 10W software defined radio module weighing just 210g, built for long-range drone links capable of over 150km line of sight.

Book A Demo
INNOVATION AT OUR CORE

ULTRA SWaP

Weight-critical airframes need serious RF performance without carrying unnecessary mass. The BluSDR-90-UL Ultra-Light delivers 10 W total RF output from two COFDM transceivers in a 210 g module, giving small platforms the link margin required for long-range missions. Its software defined architecture allows waveform and role flexibility, helping teams tailor the radio to the mission without changing hardware.

MORE INTEGRATED SOLUTIONS

INTEGRATION-READY ON SMALL AIRFRAMES

Small UxV platforms need compact interfaces that connect cleanly to payloads, control systems, and onboard networks. BluSDR-90-UL supports Gigabit Ethernet, dual USB, RS-232 serial data, analogue audio, GPIO, SBUS, and MAVLink through compact JST connectors. As a MANET radio, it forms a MeshUltra-X self-healing network of up to 144 nodes, with Interlink mode for larger systems as airframes and assets join the mesh.

PROVEN RESILIENCE

RESILIENT THROUGH HARSH ENVIRONMENTS

Long-range UxV links must withstand heat, movement, unstable power, and contested spectrum. The BluSDR-90-UL Ultra-Light operates from -20°C to +55°C with additional cooling, accepts a wide 10 to 32 V DC input, and supports adaptive modulation and self-healing routing to keep traffic moving as conditions change. DES as standard and optional AES128/AES256 encryption help protect data across MeshUltra waveforms.

LEARN MORE

10W RF OUTPUT

Two COFDM transceivers deliver 5W (37dB) per output for a powerful 10 Watt RF total.

210G LOW SWAP

Ultra-lightweight module weighs just 210g (7.4oz) at 130mm x 60mm x 15mm for weight critical airframes.

150KM+ LINE OF SIGHT

Built for long range drone links capable of over 150km line of sight, depending on environment.

144-NODE MESH

MeshUltra-X MANET waveform forms a self healing mesh of up to 144 nodes; up to 87Mbps capacity.

WIDE POWER INPUT

DC input from 10 to 32V with 120W peak inrush; external heatsink or fan for thermal management.

DUAL USB AND GIGE

Gigabit Ethernet, 2x USB, RS-232 serial, audio and GPIO via compact JST connectors; Interlink mode.

AES AND 64GB

Optional AES128/256 to FIPS140-2 for MeshUltra; 128GB internal microSD storage.

Radio architecture DTC proprietary software defined radio, multi-waveform single module
Mesh waveform DTC MeshUltra-X MANET IP Mesh, up to 144 nodes
Mesh capacity Up to 87Mbps; up to 87Mbps in 20MHz channel
Protocols SBUS and MAVLink supported
USB USB 0 host (5-way JST); USB 1 host/device configurable (5-way JST)
Gigabit Ethernet 8-way 1mm JST
Data interface RS-232 or USB peripheral; RNDIS Ethernet over USB
Audio interface Analogue microphone/headphone with bias, G726 32kbit, 8kHz sampling and mute
GPIO 6-way 1mm JST plus 3V3 out
Encryption (standard) DES
Encryption (licensed) AES128/256, accredited to FIPS140-2 for MeshUltra waveforms (subject to export control)
Storage 128GB internal microSD
COFDM RF transceiver SMA (f) 50 ohm x 2
RF power 5W (37dB) per output, 10W total
Power step 0.25dB incremental control
Tuning step 125kHz step
Bandwidth 1.25/1.5/1.75/2.5/3.0/3.5/4.0/5.0MHz (MeshUltra-M/-80/-X); 6.0 to 20.0MHz (MeshUltra-M/-80)
Carrier modulation BPSK/QPSK/16QAM/64QAM (adaptive)
FEC rate 1/2, 2/3 (adaptive)
Receive sensitivity -98dBm (BW 2.5MHz/QPSK 1/2)
Receive input level +20dBm max.
Frequency options 1.20 to 1.70GHz; 1.98 to 2.70GHz; 4.20 to 5.20GHz
Dimensions (module) 130mm x 60mm x 15mm (not incl. SMA)
Weight (module) 210g
Dimensions (heatsink assembly) 132mm x 60mm x 40mm
Weight (heatsink assembly) 300g
DC input 10 to 32V
Power consumption Peak inrush 120W; 5MHz BW with 25 to 90% occupancy 30W to 55W typ.
Temperature range -20 degrees C to +55 degrees C with additional cooling
Humidity Less than 85% non-condensing
Cooling External heatsink or fan required
MISSION OUTCOME

BluSDR-90-UL Ultra-Light puts a full 10W software defined radio onto weight critical airframes at just 210g, with line of sight reach capable of over 150km depending on environment. Compact JST interfaces, a self healing tactical mesh network of up to 144 nodes, and AES128 and AES256 encryption come in a low-SWaP module. The BluSDR-90-UL Ultra-Light keeps the link alive in contested environments.
